Deutz 914 Series Engine

Deutz 914 Series Engine

Deutz series 914 – a series of professional and consumer engines of the famous German company DEUTZ for mobile equipment. Deutz 914 engines are used on mobile industrial, agricultural installations, on vehicles. — Deutz engine Mode l F6L914.
Motors Deutz F6L914 – four-stroke 6-cylinder, diesel engine with direct fuel injection, the horizontal location of the shaft. Engine Deutz F6L914 has the following design features: cast-iron crankcase, integrated axial cooling fan, modular cylinder system convenient for separate maintenance of the desired cylinder, aluminum cylinder heads.
Forged crankshaft with counterweights,Upper valve arrangement,Two compression and one oil ring (per cylinder),Full-flow oil filter cartridge type,Fuel Filter Cartridge Type,Bimetallic camshaft bearings.Generator 14V / 55A,Electrostarters 12V.
Deutz F6L914 engines are widely used in various equipment: wheeled and crawler excavators, loaders, drilling rigs, combines, compressors, diesel generators, etc.

Contact Us Request a quote

914 Characteristics:

Air-cooled 4,6 cylinder naturally aspirated in-line-engines.
Excellent injection and combustion system.
Strong adaptive capacity to environment and high reliability.

Your benefits:

Space saving due to small installation space.
Low exhaust emissions,meets exhaust regulation EPA II.
Low maintenance requirements.

Engine model

Deutz 914 Series Engine

Technical Data

Model

F6L914

BF6L914

BF6L914C

Air-intake way

Natural Intake

Turbo Charging

Turbo Charging Cooling

No. of cylinders

6

Arrangement

Air-cooled 4 stroke in line

Displacement(L)

6.472

Bore x Stroke(mm)

102×132

Compression Ratio

20

18

18

Direction of Rotation (facing fan)

Clockwise

Electronic Governor

<1%

Outside Dimension(mm)

1083*679*821

1108*776*821

1123*714*863

Lubrication System Capacity(L)

14~20

Net Weight(kg)

420

485

510

Electric System

12V/24V

The engine for generator sets

Model

F6L914

BF6L914

BF6L914C

Frequency(Hz)

50 60

50 60

50 60

Speed(rpm)

1500 1800

1500 1800

1500 1800

Continuous Power(kW)

62 73

89 106

114 137

Prime Power(kW)

65 77

93 110

119 144

Limited-time Power(kW)

69 81

98 116

125 151

Fuel Consumption at Power Rating 100%(g/kW.h)

218 226

210 212

210 212

Fuel Consumption at Power Rating 75%(g/kW.h)

230 240

219 229

228 225

Fuel Consumption at Power Rating 50%(g/kW.h)

246 264

240 240

244 236

Fuel Consumption at Power Rating 25%(g/kW.h)

281 289

260 278

270 275

The engine for construction equipment

Model

F6L914

BF6L914

BF6L914C

Speed (rpm)

2300 2500

2300 2500

2300 2500

Power(kW)

79 85

112 115

125 137

Max Power(kW)

82 88

115 118

128 141

Speed at Max Torque (rpm)

1600

Max Torque(N.m)

400

550

690

Specific Fuel Consumption(g/kW.h)

209

206

206

Minimum Ldle Speed(rpm)

<750

The engine for construction equipment

Model

F6L914

BF6L914

BF6L914C

Speed (rpm)

2300 2500

2300 2500

2300 2500

Power(kW)

79 85

112 115

125 137

Max Power(kW)

82 88

115 118

128 141

Speed at Max Torque (rpm)

1600

Max Torque(N.m)

400

550

690

Specific Fuel Consumption(g/kW.h)

209

206

206

Minimum Ldle Speed(rpm)

<750
